Ruijie-Reyee RG-NBS5200-24SFP/8GT4XS 24-Port SFP Layer 3 Managed Switch

24 SFP Ports: Equips 24x 100/1000Base-X SFP slots for fiber connectivity, ideal for long-distance links in campus or enterprise networks using modules like GE-SFP-LH40-SM1310-BIDI.
8 Gigabit RJ45 Combo Ports: Provides 8x 10/100/1000Base-T RJ45 combo ports, offering flexible copper connectivity for devices like HPE ProLiant servers or the Lenovo Legion 7 16IAX10.
4x 10G SFP+ Uplink Ports: Features 4x 10GBase-X SFP+ slots for high-speed uplinks (up to 80km with modules like 10GE-SFP-LR-SM1310), enabling robust backhaul to core switches or routers like the RG-EG310GH-E.
Non-PoE Design: Optimized for data-only networks, reducing power consumption for environments not requiring PoE devices like APs or cameras.
Layer 2+ Management: Supports VLAN (up to 4094), QoS for traffic prioritization, IGMP snooping (v1/v2/v3), link aggregation, and static routing for efficient network segmentation.
Static Routing: Enables basic inter-VLAN routing, enhancing flexibility for SME or campus networks without full Layer 3 routing protocols.
Ruijie Cloud Management: Provides remote configuration, monitoring, and diagnostics via the Ruijie Cloud platform or mobile app, simplifying network administration.
IP Camera Recognition: Enhances CCTV networks with automatic IP camera detection, NVR integration, offline alarms, and remote port reboot, ideal for surveillance with external PoE switches.
Self-Organizing Network (SON): Facilitates zero-touch provisioning for plug-and-play setup, automatically configuring VLANs and ports using QR code scanning.
6 kV Surge Protection: Shields ports from electrical surges, ensuring reliability in environments with unstable power conditions.
High-Performance Switching: Delivers 128 Gbps switching capacity and 96 Mpps forwarding rate, supporting data-intensive applications in enterprise networks.
19-Inch Rack-Mountable Steel Case: Robust 1U design (440mm x 267.5mm x 43.6mm, ~3.35 kg with package) for data centers or server rooms.
Single Fan Cooling: Features one fan with left-to-rear airflow for efficient cooling, maintaining low noise levels (<45 dB) for office or classroom settings.
Comprehensive Security Policies: Includes CPU Protection Policy (CPP), port security, IP source guard, anti-ARP spoofing, DHCP snooping, and ACLs to protect against network threats.
Link Aggregation (LAG): Supports up to 16 groups with 8 members per group for increased bandwidth and redundancy, enhancing connectivity to devices like the DL380 Gen11 server.
