Ruijie-Reyee RG-NBS5200-24GT4XS-P 24-Port Gigabit Layer 3 Managed PoE Switch.

24 Gigabit PoE+ Ports: Equips 24x 10/100/1000BASE-T RJ45 ports with PoE/PoE+ (IEEE 802.3af/at, up to 30W per port), ideal for powering IP cameras, VoIP phones, or APs like the RG-RAP2260(E).
370W PoE Power Budget: Supports ~12 PoE+ devices at full 30W or more at lower power, suitable for enterprise CCTV or wireless networks.
4x 10G SFP+ Uplink Ports: Features 4x 10G SFP+ slots for high-speed fiber uplinks (up to 80km with modules like 10GE-SFP-LR-SM1310), enabling high-bandwidth backhaul to core switches or routers like the RG-EG310GH-E.
Layer 3 Management: Supports static routing, RIP, OSPF, and Virtual Cluster Switching (VCS) for advanced inter-VLAN routing and network scalability in campus or enterprise environments.
Ruijie Cloud Management: Provides remote configuration, monitoring, and diagnostics via the Ruijie Cloud platform or mobile app, simplifying network administration for SMEs.
IP Camera Recognition: Optimizes CCTV networks with automatic IP camera detection, NVR integration, offline alarms, and remote port reboot for seamless surveillance deployments.
Self-Organizing Network (SON): Facilitates zero-touch provisioning for plug-and-play setup, automatically configuring VLANs and ports without cloud dependency.
6 kV Surge Protection: Shields PoE ports from electrical surges, ensuring reliability in environments with unstable power conditions.
High-Performance Switching: Delivers 128 Gbps switching capacity and 95.24 Mpps forwarding rate, supporting data-intensive applications in enterprise networks.
19-Inch Rack-Mountable Steel Case: Robust design (440mm x 357.6mm x 43.6mm, ~4.4 kg with package) supports 1U rack mounting for data centers or server rooms.
Dual Fan Cooling: Features two fans with left-to-right airflow for efficient cooling, maintaining low noise levels (<45 dB) for office or classroom settings.
Comprehensive Security Policies: Includes CPU Protection Policy (CPP), port security, IP source guard, anti-ARP spoofing, and DHCP snooping to protect against network threats.
Link Aggregation (LAG): Supports up to 8 members per group for increased bandwidth and redundancy, enhancing connectivity to devices like HPE ProLiant servers.
High Reliability: Boasts an MTBF >200,000 hours, ensuring long-term stability, backed by a 5-year warranty (region-dependent).
Loop Detection and Storm Control: Prevents network loops and mitigates broadcast storms, ensuring stable performance in complex network topologies.
